ANTENNA TYPE

Kymeta u8 GEO Terminal with integrated LTE capability

DIMENSIONS

W 89.5 cm × D 89.5 cm × H 14 cm

TOTAL WEIGHT

34 kg (75 lb.)

(includes modem, hybrid card)

FREQUENCIES

TX 13.75 – 14.5 GHz

RX 10.7 – 12.75 GHz

POLARISATION

Vertical and horizontal, software defined

(circular with software upgrade)

EIRP

Up to 46.5 dBW with 20 W BUC

SCAN ANGLES

Az 360°, El +15° to +90°

G/T BROADSIDE

9.5 dB/K to 12 dB/K

POWER CONSUMPTION (WITH INTEGRATED MODEM)

130 W (typical)

250 W (peak)**

DC INPUT POWER

12 VDC to 36 VDC max

NETWORK INTERFACE

Ethernet, WiFi

RF CABLES

N-type connectors

CERTIFICATIONS IN PROGRESS

CE, UL, RoHS, FCC

OPERATIONAL TEMPERATURE

-40° C to +55° C (ambient)

-40° C to +70° C (with solar load)

AVAILABLE CONFIGURATION

Integrated antenna control unit and power supply

iQ 200 modem and multi-WAN device with either global LTE or LTE Band 14 configuration

RF chain with 20 W low-profile BUC

Shroud

AVAILABLE ACCESSORIES

Vehicle mount kit

Vehicle power kit

AC-to-DC power kit
