Offering truly global pole-to-pole coverage, Intellian C700 is powered by the Iridium Certus network of 66 LEO satellites and can be deployed as the primary onboard communications antenna or as a companion to the existing VSAT system. The all-in-one winterised terminal simultaneously supports three HD quality low-latency voice lines and can deliver uplink speeds of 352 Kbps and downlink speeds of 704 Kbps to ensure seamless connectivity in all weather conditions, including extreme low temperature environments. Intellian Certus C 700 is a solid-stateantenna with no moving parts, requiring no scheduled maintenance over its lifetime.
Antenna: 7.3 kg
Terminal: 1.2 kg
Antenna: 370 x 270 mm
Terminal: 280 x 190 x 41 mm
Antenna: -50°C to +55°C
Terminal: -15°C to +55°C
> 95%
Water, shock, and vibration-resistant, winterised terminal for extreme environments
Antenna: 10.8 V to 30 V DC
Heating Device: 220 V AC, 0.91 A
Antenna: 120 W
Up to 352 Kbps (uplink);
Up to 704 Kbps (downlink)
1616.0 MHz – 1626.0 MHz
1616 MHz – 1626.5 MHz
TNC female (ADU) – TNC female (BDU)
GPS
GLONAS
GALILEO
LAN: 3 x RJ45
WAN: 3G/4G/LTE WAN PORT
WIRELESS: 1 Wi-Fi (SMA-RP)
I/O: 10 PIN GPIO
3 simultaneous HD quality voice lines
Up to 2 analog telephones
Soft PABX for up to 16 SIP Phones
Built-in Analog Terminal Adapter (ATA)
Built-in Power-over-Ethernet (PoE)
Built-in Private Automatic Branch Exchange (PABX)
Built-in Router
Built-in Firewall
Built-in WAN
Built-in WiFi
CE/RED
FCC
C700 Terminal
Antenna
DC Power Cable
Antenna Cable (25m)
Ethernet Cable (3m)
WiFi Antenna
