With three high-quality voice channels and up to 176 kbps data, LT-4200S GMDSS System is powered by Iridium Certus® 200 and meets all the certification requirements for onboard GMDSS equipment (IMO MED & Wheelmark + SSAS/LRIT). This state-of-the-art communications system offers 100% global coverage and operates between a broad temperature range. LT-4200S GMDSS System can easily be adapted as the primary communications product onboard small vessels, ship-to-shore as well as ship-to-ship, and deliver a stable back-up link for larger vessels. The single cable solution connects the control and antenna units, and the coaxial cable offers freedom to mount the antenna up to 150m apart. With a built-in webserver, large 4.3” TFT display, and a resilient design, LT-4200S GMDSS System is the perfect safety & communications system onboard any vessel.
Control Unit: 658 g
Antenna Unit: 3.70 kg
Handset: 290 g
Control Unit: 224.0 x 120.0 x 70.0 mm
Antenna Unit: 238.7 x 224.6 mm
Handset: 208.8 x 52.8 x 38.2 mm
Control Unit and Handset: -15°C to +55°C
Antenna Unit: -40°C to +55°C
Control Unit and Handset: IP32
Antenna Unit: IP67
176 kbps (up/down)
3 x High-quality voice channels
Distress Alert
Distress Call
Maritime Safety Information (MSI)
SOLAS GMDSS Approved for Sea Areas A1, A2, and A3
MED Module B+D, RED (CE), FCC, ISED, ROHS2, Iridium
Ship Security Alert System (SSAS)
Long Range Identification and Tracking (LRIT)
High-performance GNSS/GPS receiver
Single antenna cable solution(up to 150m)
Large 4.3″ TFT display
Web server for configuration and maintenance
Support for remote alarm panels
Support for GMDSS printer
Support for Bridge Alert Management (BAM)
LT-4210S Control Unit
LT-3120 Handset
LT-3121 Cradle
LT-4230 Antenna Unit
Bracket Mount, Control Unit
Power Cable, 3m
Stainless steel A4 screws for mounting
User & Installation Manual
Unit Test Sheets
